Split AC Installation (3 AC)

About the service

Our Split AC Installation for 3 AC units is for homes, offices, clinics, hostels and PGs where you want three Split ACs installed in one planned visit. This service supports 0.75 ton, 1 ton, 1.5 ton and 2 ton Split ACs, inverter and non inverter, for any brand.

You can install three same ton units or any mix of tonnages. For example. 1 ton + 1 ton + 1.5 ton, or 1 ton + 1.5 ton + 2 ton, or three 2 ton units for bigger rooms. We handle full indoor and outdoor unit mounting, standard piping, wiring connection, vacuum and leak testing for all three ACs so every room gets stable, efficient cooling from day one.

Best for.

• 3 BHK flats and family homes

• Three bedrooms or two bedrooms plus hall

• Clinics, coaching centres, salons or offices with three rooms

• Re installation of three units after shifting or renovation

Our process

1. Site check and planning for 3 ACs
The technician inspects all three rooms and the possible outdoor mounting locations. They check wall strength, balcony or façade space, power point positions and drain route options. Based on tonnage and layout, they decide the indoor position and outdoor placement for each Split AC for best airflow and service access.

2. Indoor unit mounting . AC 1 . AC 2 . AC 3
Mounting plates are fixed on strong, level walls in each room. Indoor units are positioned so that the airflow does not hit directly on the face, with proper clearance from ceiling and side walls. Holes are marked and drilled for copper pipe and drain line for all three ACs.

3. Outdoor unit mounting for all three ACs
Outdoor units are placed on wall brackets, balcony stands or floor stands as per site condition. Each unit is leveled properly to reduce vibration and noise. Adequate gap is kept between outdoor units so hot air can discharge freely and future service access is easy.

4. Piping, drain and wiring connection
For each AC, copper pipe with insulation, drain pipe and interconnecting cable are routed between indoor and outdoor units within the standard length included in your plan. Joints are tightened correctly to avoid refrigerant leakage. Drain pipes are laid with proper slope so water flows out safely without dripping inside any room.

5. Vacuum and leak test for 3 systems
A vacuum pump is used on each system to remove air and moisture from the refrigerant lines. All joints are checked for leaks using proper testing methods. This is critical for compressor life and cooling performance, especially on inverter models and higher tonnage units.

6. Gas release and performance test room wise
Factory charged refrigerant is released into all three systems. The technician runs each Split AC in cooling mode and checks airflow, temperature drop, vibration, noise and drainage in every room. Only after confirming stable operation is the installation marked complete. You get a short demo on modes and basic maintenance.

What we need from you

• Three suitable indoor walls finalized for mounting

• Clear outdoor space or façade area for three outdoor units

• Working power sockets or MCB lines for all three ACs

• Wall brackets or stands ready, or your approval to fit new ones

• Ladder or safe access if any outdoor unit will be at height

• Permission for drilling holes for pipes and drain in all three rooms

What is usually included . and what is extra

Included in standard installation for 3 ACs

• Indoor mounting plate fixing for all three units

• Outdoor placement on existing brackets or stands

• Connection of standard copper pipe length, drain pipe and interconnecting cable for each AC as per your policy

• Vacuum and leak testing for all three systems

• Cooling test and basic user demo room wise

Chargeable extras as per site condition

• Extra copper pipe length beyond standard for any unit

• Extra drain pipe, casing or trunking

• New outdoor wall brackets or floor stands

• Core cutting, heavy drilling or major civil modifications

• New electrical wiring, MCB or stabilizer

Why choose this Split AC installation service

• Supports 0.75 ton, 1 ton, 1.5 ton and 2 ton Split ACs

• Ideal for 3 BHK homes, clinics, offices, hostels and PGs

• Handles same ton or mixed ton combinations in one visit

• Proper vacuuming and leak testing for all three ACs

• Clear separation between standard installation scope and extra material charges

Frequently asked questions

Q1. Can I install three different tonnage Split ACs under this service
Yes. You can mix any combination of 0.75 ton, 1 ton, 1.5 ton and 2 ton, inverter or non inverter, as long as all three ACs are at the same address.

Q2. Is gas filling included in this installation
No. New units usually come factory charged. If a used AC needs gas top up because of previous work, gas filling is charged separately per unit.

Q3. Does this include stabilizers and new electrical wiring
No. If stabilizers and wiring already exist, the technician will connect the ACs to them. Any new wiring, MCB or stabilizer is extra.

Q4. How much time does installation of 3 Split ACs take
Normally 3 to 5 hours, depending on floor level, outdoor access, wall type and pipe routing distance.

Q5. Will you repair or repaint the wall after drilling
Basic hole closing can be done if required. Full wall finishing, repainting or POP work is not part of the installation service.
